PDH SERIES LAGRE FORMAT&TONNAGE

HEAVY DUTY CNC PRESS BRAKE

Features

●Product specifications can be customized according to customer requirements,with a maximum specification of up to 16 meters and 5,600 tons;
●Various structural forms of auxiliarymachine configurations are availablefor customers to choose from;
●Rich tooling design experience is provided to offer the optimal bending solution;
●Supports tandem and multi-machine linkage expansion

●Shipbuilding,construction machinery,electric power towers,lighting poles,bridge steel structures, axle frames, etc

Product details:

SPECIFICATION

SPECIFICATION		UNIT	500/5000	500/6000	600/5000	600/6000	600/8000	800/6000	800/8000	1000/6000	1000/8000	1200/8000	1200/12000	1600/8000	1600/12000
Bending Force		kN	5000	5000	6000	6000	6000	8000	8000	10000	10000	12000	12000	16000	16000
Bending Length		mm	5000	6000	5000	6000	8000	6000	8000	6000	8000	8000	12000	8000	12000
Column Distance		mm	4000	5000	4000	5000	6400	5000	6400	5000	6400	6400	9000	6400	9000
Throat Depth		mm	500	500	500	500	500	600	600	600	600	600	600	800	800
Slide Stroke		mm	300	300	300	300	300	400	400	400	400	400	400	500	500
Open Height		mm	600	600	600	600	600	700	700	700	700	700	700	1000	1000
CNC Axes		3+1	Y1、Y2、X、V
Main Motor Power		kW	37	37	45	45	45	75	75	90	90	90	90	2×55	2×55
Oil TankCapacity		L	1000	1200	1200	1200	1400	1800	1800	1800	2000	2000	2400	3000	3000
Speed	Approaching	mm/s	100	100	90	90	90	80	80	80	80	70	70	70	70
	Working	mm/s	8	8	8	8	8	7	7	7	7	6	6	6	6
	Return	mm/s	90	90	90	90	90	80	80	80	80	60	60	60	60
Overall Dimensions	Length	mm	5300	6300	5300	6300	8300	6400	8400	6400	8400	8400	12400	8400	12400
	Width	mm	2260	2260	2400	2400	2400	3000	3000	3100	3100	3200	3200	3300	3300
	Height	mm	4200	4500	4200	4500	4600	5200	5400	5300	5800	6000	7500	7000	9000
